Defining a Curve on the drawing

Hi guys,

what's the best way to define part with curved shape?

Please see the picture attached.

I need to make a drawing of this part. And what I was planning on doing is to place the points along the curve and dimension them within the coordinate system.

When I add sketch points to the curve, the dimension doesn't grab them and doesn't dimension them.

When I try to add points in the model, it's not very straight forward.




Your help is highly appreciated.

1 REPLY 1
TomD.inPDX
17-Peridot
(To:pvn)

RMB+hold@selection to get the selection menu and choose "pick from list".  There you will find your point element as long as it is visible.
