flattening cable assemblies

mbabu
10-Marble
10-Marble
‎Jun 22, 2022 08:01 AM
‎Jun 22, 2022 08:01 AM

flattening cable assemblies

I am using Creo Parametric - Release 3.0 (connected) Release 3.0 and DatecodeM190

we have issue on flattening some cables

Labels:
0 Kudos
Notify Moderator
1 REPLY 1
Lars_F
14-Alexandrite
14-Alexandrite
(To:mbabu)
‎Jun 26, 2022 02:07 PM
‎Jun 26, 2022 02:07 PM

Hello,



Flattening may be difficult for large harnesses. If your cable is routed correctly, without any errors, then there is a very instructional video series in youtube over the flattening process... https://www.youtube.com/watch?v=WVX_RNU4kSI

Creo Parametric - Cabling Flat Harness (Part 1)
Creo Parametric - Cabling Flat Harness (Part 1)
youtube.com/watch?v=WVX_RNU4kSI
This Creo Parametric tutorial shows how to start a flat harness manufacturing model of a cabling assembling, setting the Start Point, and using the Auto Fan command - and shows why this is not a good idea. It then shows a couple examples of Manual Fan. Part 2 will complete the layout of the ...
