How to pick variable NOTES: while uploading Format to a drawing

[Yogesh.T]

We have three variations of Notes:

1.Generic

2.Harness

3.Fabrication and Assembly

How to let system give me option to use what I want on drawing in NOTES: ?

SEE IMAGE

[Catalina]

Hi @Yogesh.T

Thank you for your question.

Your post appears well documented but has not yet received any response. I am replying to raise awareness. Hopefully, another community member will be able to help.

Also, feel free to add any additional information you think might be relevant.

Best regards,

[Chris3]

We do this with a mapkey that calls different notes, not with the format. There is an import text from file option that can be used with a mapkey.

[Yogesh.T]

Can you make a test case example? It might be golden for others to use and PTC to learn and grow. Thanks!

Someone gave me idea of using SYMBOL with variables. I am going to try that soon and post the outcome.

[Chris3]

An example really depends on what you want to do. Ours is quite complicated because it detects the drawing size and then launches an external app that allows users to pick notes before importing them on the drawing. The foundation for this is explained here:

https://community.ptc.com/sejnu66972/attachments/sejnu66972/customization/13797/1/VG-4052%20Dynamic%20Mapkeys%20to%20Automate%20Creo%202024-01-23.pdf

If you just want to import a text file then all you need to do is turn on mapkey recording while performing the clicks and then the mapkey will automate those same clicks the next time you run it.

In the drawing, on the annotation tab -> annotation group -> Note drop down -> Unattached note -> Absolute CSYS -> in the format tab -> Note from File
