Part Text Vertical Protrusion

How to protrude image 1 text vertically as in image 2 drawing?

4 replies

MikeBennett
MikeBennett17-Peridot
17-Peridot
Dec 18, 2025 7:18 PM UTC

Hi @Yogesh.T ,



According to CS63567, this cannot be done in a single text field in a sketch and multiple text fields should be used.



Hope this helps,

Michael

Translate
    KenFarley
    KenFarley21-Topaz II
    21-Topaz II
    Dec 20, 2025 12:46 AM UTC

    A discussion on somewhat the same topic from long ago (2016) initially asked by me. Doesn't seem like the capability of doing this exists yet, as far as I know.

    https://community.ptc.com/t5/3D-Part-Assembly-Design/Vertical-text-creation/m-p/355053

    Translate
    Srinivasan-Iyer15-Moonstone
    15-Moonstone
    Dec 23, 2025 11:46 AM UTC

    This still doesn't exist. Back then on WF2 or 3 I had to create a pattern of letters for a dial. Did it by dimension patterning a group (pattern as a place holder), Unpatterning and then changing the values. Later on, created a parameter & relation for the instances. I forgot how I did it.

    Translate
    Knowing, what we know is just a fistful of Earth, brings in humility.
    anursinghCommunity Manager
    Community Moderator
    Dec 29, 2025 4:17 PM UTC

    Hi @Yogesh.T,



    I wanted to see if you got the help you needed.

    If so, please mark the appropriate reply as the Accepted Solution. It will help other members who may have the same question.
    Of course, if you have more to share on your issue, please pursue the conversation.



    Thanks,
    Anurag
