Total length of several arcs in creo parametric 2.0

  • December 14, 2016
  • 1 reply
  • 1092 views

Anyone who knows how to annotate the total length of several arcs that are put together after each other?



See Attached image.



I would like to see the arc length from top to the red recangle.


This thread is inactive and closed by the PTC Community Management Team. If you would like to provide a reply and re-open this thread, please notify the moderator and reference the thread. You may also use "Start a topic" button to ask a new question. Please be sure to include what version of the PTC product you are using so another community member knowledgeable about your version may be able to assist.

1 reply

M
MartinHanak24-Ruby III
24-Ruby III
December 14, 2016

Hi,

if I understand you well, you want to generate picture shown in PDF file in ProE WF5 with basic license. Basic license does not provide advanced rendering functionality, therefore your rendering tools are limited.

Maybe you can test Keyshot demo version...

MH
