Thermal Analysis with multiple assemblies

  • July 16, 2024
  • 1 reply
  • 1097 views

Hi Guys,

Im running a simulation that is running based off of the subassembly sets of heat load and convection boundaries.

For example:
Assembly 1 has 1 heat load, with 7 conv boundary conditions
Assembly 2 has 1 heat load with 4 conv boundary conditions
Assembly 3 has 1 heat load with 3 conv boundary conditions

these Heat loads and convection boundaries were added to the sub assemblies, the new assembly of these 3 has not had any additional heat loads added.

how do i run a thermal analysis with all 3 heat loads working together.  It seems like the only issues are the 3 heat loads. The convection boundaries seem to run fine. It wants me to choose a single load set for the new assembly. It will not allow me to use all 3 load sets at once.




1 reply

Community Moderator
July 22, 2024

Hi @BV_10792443,

Thank you for your question.

Your post appears well documented but has not yet received any response. I am replying to raise awareness. Hopefully, another community member will be able to help.

Regards,

Vivek N

Community Moderation Team
