Question

Scale Bar Symbol

  • January 31, 2017
  • 1 reply
  • 2937 views

Does anyone have a scale bar symbol they would be willing to share?

MY current boarders don't use scale bars but 1 client has asked for them

    1 reply

    T
    23-Emerald IV
    TomU23-Emerald IV
    23-Emerald IV
    January 31, 2017

    Do you mean something like this:

    If so, what is your sheet (paper) size?

    C
    cdown1-VisitorAuthor
    1-Visitor
    January 31, 2017

    No the old scale bar which normally went on top of old drawings civils still use them:-

    scale bar.PNG

    This will be used on all size formats

    B
    23-Emerald III
    BenLoosli23-Emerald III
    23-Emerald III
    January 31, 2017

    Very tricky to be accurate in todays world of laser printers and auto-scaling. It may be accurate in the CAD file itself at 1:1, but almost all plotted/printed drawings are scaled to some extent.

    Your better solution is this on your drawings: DO NOT SCALE DRAWING
