Question

Is there a way to load 3D model from Thingworx repository to Experience dynamically ?

  • July 16, 2024
  • 1 reply
  • 2085 views

The scenario is that we are thinking to get the 3d models from windchill to thingworx and then to vuforia studio.

What can be the best scenario?
1) Integration of thingworx with windchill (any documentation)

Or

2) We upload the 3d models in thingworx repositry and fetch them in vuforia studio? if possible is there more information about the process?

1 reply

R
RolandRaytchev21-Topaz I
21-Topaz I
July 16, 2024

Hi @MA8731174 ,

for the point 1.) data migration from  Windchill to Thingworx repository , please, contact the Windchill Customization Visualisation group/ believe configuration the worker to export data  which could be imported later - or /possibly the bether option/ you can check the Thingworx naviage so you can post your quesiton  in the Thingworx developement communty - Thingworx Navigate communty https://community.ptc.com/t5/ThingWorx-Navigate/bd-p/thingworxnavigate . So far I have informaiton from the Navigate team  there are some kind of connectors which coould be customized to different tasks and possibly this could be hepful for you to manage this task. Please, address the quesiton 1.) there . Thanks



to point 2)  - let say you have all data already uploaded to a folder into a think which is created from FileRepository template. In this case you can use the LoadBinary service  to start  downlaod and then to received the model in the LoadBinary-complete event some think like that:

//---loading the model
$scope.app.LoadModel = function(widgetName,path ) {
 console.warn("$scope.app.LoadModel(",widgetName,",src,",path,")")
 $scope.wdgName=widgetName
 $scope.serviceName='LoadBinary'
 $scope.repositoryThing='CADRepository1_test'
 var parameters = {"path":path} ; console.warn(parameters)

 twx.app.fn.triggerDataService($scope.repositoryThing,$scope.serviceName,JSON.parse(JSON.stringify( parameters)));
 $scope.$applyAsync();
 console.log("after callLoadBinaryContent wdgName:"+$scope.wdgName)
};


//========== the LoadBinary-complete event
$scope.$root.$on('LoadBinary-complete', function(event, args) {
 console.log("LoadBinary-complete event");console.log("name="+event.name)
 console.warn(args.data[0].Content)
 $scope.$applyAsync();

 $timeout((data)=>{

 $scope.setWidgetProp( $scope.wdgName,'src',data );
 $scope.$applyAsync();
 },500,true, args.data[0].Content)
});

So in the example it will set the received data to the src of a model widgit (name of the widgit is in the variable $scope.wdgName. So to work that you need to add the Thingrepository to the external data /here CADRepository1_test and the service LoadBinary

Also all data and services which should be accessed in Vuforia Studio should be conigured according the Studio help:

https://support.ptc.com/help/vuforia/studio/en/#page/Studio_Help_Center%2FAnonymousAccess.html%23

https://support.ptc.com/help/vuforia/studio/en/#page/Studio_Help_Center%2FGrantUserPermissions.html



    M
    MA873117416-PearlAuthor
    16-Pearl
    July 17, 2024

    Thank you @RolandRaytchev for always supporting the community.  you are passing data in the timeout function but the data itself is deriving from args. can you please see now i am taking the data and i mean content below and assigning it to model.



    $scope.$root.$on('LoadBinary-complete', function(event, args) {
 console.log("LoadBinary-complete event");console.log("name="+event.name)
 console.warn(args.data[0].Content)
 $scope.$applyAsync();

 let a =args.data[0].Content


 $timeout((a)=>{
 console.log("yes",a);
 $scope.setWidgetProp( $scope.wdgName,'src',a );
 $scope.$applyAsync();
 },500,true, args.data[0].Content)
});







    service response below




    error for now




    this is pvz file which i am taking from thingworx repositry and setting it to the model.

      R
      RolandRaytchev21-Topaz I
      21-Topaz I
      July 25, 2024

      Hi @MA8731174 ,

      so far it should work but it seems that it has an issue to get the whole data at one piece ... not sure, at all. The data is printing OK and I remember that was working in the past.

      So possibly with small pvz that will work , e.g. some cube  pvz with small size to see if that issue is still there.

      I looked in some of my projects and see that I was also faced with this issue in the one of the 9.15+ version and used a different approuch  which  was working on mobile... some code like that:



      //===========================================================
// Event : LoadBinary-complete
//===========================================================
$scope.$root.$on('LoadBinary-complete', function(event, args) {
 console.log("LoadBinary-complete event");console.log("name="+event.name)
 console.warn(args.data[0].Content)

 const blob = dataURItoBlob(dataURI);//---- //possibly this blob get the whole object from server and not only part of it!!!
 //because otherwise it does not make any sense but without this it did not work at all
 console.warn("blob = ");console.warn(blob)
const objectURL = URL.createObjectURL(blob);

 $scope.setWidgetProp( 'textArea-1','text',JSON.stringify(objectURL).slice(0,100) );
 $scope.$applyAsync();
 //https://developer.mozilla.org/en-US/docs/Web/API/HTMLMediaElement/srcObject

 $timeout((data)=>{

 $scope.setWidgetProp( $scope.wdgName,'src',data );
 //$scope.setWidgetProp( $scope.wdgName,'scale',$scope.app.curr_scale );
 $scope.app.params.scale=$scope.app.curr_scale

 for(let i=0; i<11;i++) $timeout(()=>{$scope.$applyAsync(); },50*i);
 },500,true,'data&colon;image/pvz;base64,'+ args.data[0].Content)

});
//-----------------------------------------------------
$scope.app.LadeModelTest=()=>{
console.log("only print for the LadeModelTest to see that it was called");
//$scope.app.LadeModel('model-1','/CAD/Engine_Low.pvz')
 // $scope.app.LadeModel('model-1','/pvz/mill5MT_High.pvz')
 $scope.app.LadeModel('model-1',$scope.app.randomMod())
};



      code is not really a good programming style example ... but tested in the 9.21 with project and it worked - tested now in preview - is ok. So far I see your issue is in preview - so frist there to check. I will attach a demo project


      To get the project working without many changes you need to have a repostitory thing with the name

      const TWXmodelID = 'CADRepository1_test'

      or you have to change the code line 6 on Home.js to the name of the repository what you use

      Also you have to load some files into a folder of your repository . Add that information in the Lines 37-45



       $scope.app.ListeMods=[
 {'name':'3dgauge1','pvz':'/pvz/3dgauge1.pvz','scale':3},
 {'name':'bla-bla','pvz':'/pvz/bla-bla.pvz','scale':3},
 {'name':'engine_test_exp','pvz':'/pvz/engine_test_exp.pvz','scale':0.5},
 {'name':'mill5MT_High','pvz':'/pvz/mill5MT_High.pvz','scale':1},
 {'name':'navipad','pvz':'/pvz/navipad.pvz','scale':2},
 {'name':'ventil_bg_anno','pvz':'/pvz/ventil_bg_anno.pvz','scale':3},
 {'name':'wandregal','pvz':'/pvz/wandregal.pvz','scale':0.5}
 ]



      here you should provide information abouth the name, pvz filename and Studio display scale... so means you can change that informaiton according to the used repository folder and data what is loaded there.

      Also you need to add LoadBinary into the external data section / so first remove the old objects and recreate the bindings again

      Also,please,  take care that LoadBinary service has the correct permission in TWX  but I think that is something what you alreay set ... so regarding  the status of the provided pictures

      I hope that helps! If not then, please , let me know. Thanks
