How do I save images of parts that are suitable for patent applications (i.e. no shading, single outline edges)?

  • September 14, 2016
  • 3 replies
  • 5653 views

Hi.

I have parts designed in Elements/Direct that I need to save as images for submission in a patent application. These images must not have any shading and single black outline edges else they will be rejected.

I have experimented in the Part Properties and Realism pop-out menu, but can't get what I need. The best I can do is to turn off 3d shading in the Realism menu and just show the edges. However, with these settings, faces that curve away out of view do not have a line showing that surface that you see tangentially from that perspective. Hope you know what I mean.

What settings do I need to choose or is there some other way to generate unshaded images with solid black edge outlines?

Thanks

Rajesh

3 replies

23-Emerald III
September 14, 2016

Toby Metcalf‌ can move this to the Creo Elements/Direct‌ forum to get the right eyes on it.

I don't know how Elements direct works but have you thought about making simple drawings to get the views you need?

5-Regular Member
September 14, 2016

Good day Rajesh - as Stephen Williams‌ suggested, would you like me to move this?

Best,

Toby

rjethwa7-BedrockAuthor
7-Bedrock
September 14, 2016

Hi Toby

Yep, sounds fine to move, thanks.

Stephen - what do you mean when you say 'simple drawings'? It that a specific function/option?

Thanks

Rajesh

23-Emerald III
September 14, 2016

Drawings are the typical method of sharing information within 3d models. This one was done in Creo Parametric not Elements direct.

I'm sure that elements/direct has a drawing/drafting function but I am not familiar with the software.

Image below is a drawing of a tool we provide.

14-Alexandrite
September 14, 2016

Hello Rajesh,

You will need to use the Annotator (Annotation) module in Creo Elements/Direct Modeling to create 2D views of parts/assemblies. You can create Isometric views and then simplify the contents of the views by removing hidden lines, tangential lines, etc.. from the view.

Thank you.

Cheers,

Thom

rjethwa7-BedrockAuthor
7-Bedrock
September 15, 2016

Thom - Aha... yes, I see that's what I need.

So I have tried having a go with that, but I only seem to be able to view individual parts from the different axis; can't get multiple pieces to show at the same time.  I have tried (again) looking for tutorials on YouTube, but can't find anything specific on just Annotation - any suggestions on this would be great please?

Many thanks

Rajesh

14-Alexandrite
September 15, 2016

Hello Rajesh,

The only way to add multiple parts into a single view is to have them set-up as an assembly in Modeling, then choose the assembly as the top level that the views will be created from.

Regards,

Thom
