Volume of a cavity within an assembly

  • January 5, 2011
  • 4 replies
  • 4562 views

Good Morning ProE/Creo experts,

Is there an easy way to determine the volume of a cavity in an assembly? I could create a dummy model of the cavity and determine the volume of the dummy but it is a fairly complex shape and I am hoping there is a more efficient way of accomplishing this task.

WF 4.0, M120

TIA

Jim Majewski


This thread is inactive and closed by the PTC Community Management Team. If you would like to provide a reply and re-open this thread, please notify the moderator and reference the thread. You may also use "Start a topic" button to ask a new question. Please be sure to include what version of the PTC product you are using so another community member knowledgeable about your version may be able to assist.

4 replies

I
IainLewis1-Visitor
1-Visitor
January 5, 2011
Jim,



The way I would approach this is;

1. Create an assembly

2. Assemble in your part

3. Create a new empty part.

4. Activate the empty part.

5. Select all the internal surfaces (Using seed and boundary
selection ie Pick internal surface, hold shift, pick capping surfaces)

6. Copy and paste the selection, use Ctrl + C, then Ctrl +V.

7. Open the Part with the new surfaces in.

8. Cap the surfaces.

9. Merge them all together.

10. Solidify and run the volume analysis.



I'm sure that there are quicker ways but this would be a good starter
for 10. I can send you a video if required.



Regards



Iain



I
IainLewis1-Visitor
1-Visitor
January 5, 2011
A file has been sent to you via the YouSendIt <">http://www.yousendit.com>
File Delivery Service.
Download the file - internal_volume.avi
<">https://www.yousendit.com/download/RlRvbGtJeDNYSHcwTVE9PQ>
Your file will expire after 7 days or 100 downloads.


All,



I've had a couple of requests for this video.



Please find this, as requested, attached. (Via yousendit)



As an FYI you may have to download the tscc codec.



Regards



Iain



P
patharris1-Visitor
1-Visitor
January 5, 2011
Hello Iain,
A more general technique (talking WF4) we use is to create publish geometry
in the model or assy that you want to measure the volume in and to put this
geometry into the empty part (volume_X.prt?) as a >shared geometry >copy
then selecting the published geometry. This seems to have an advantage over
the cut, paste technique in that this will update in the case of changing
volumes and you can redefine the publish geometry. The downside of this
technique is that you need the AAX module which is not in Foundation. Is
this true, or am I missing something?

Regards,

Pat Harris
Principal Engineer
Product Design, Inc.
5133 Washington St., Suite 9
Downers Grove, IL 60515
C
cdspk1-Visitor
1-Visitor
January 6, 2011

Assemble a cube which overlaps the extents of the cavity x, y and z

Edit > Component Operations > Cut Out

Pick the cube to be cut

Ctrl pick the components which create the cavity to cut the cube.

Find the volume of the cut cube part

Sean
